Engineering design and product development
SolidWorks engineering design, sheet metal work, PCB design and EPLAN — from the concept to the production-ready drawing.
References
References under non-disclosure.
Our test benches stand in development departments and test fields, at products that cannot yet be bought. What we are allowed to show publicly is a fraction of what we have built — and that is deliberate.
Customers
Who we have built for
A selection of the companies for which plants have been built by us. In most cases we may not state more than the name.
The brands and logos are the property of the respective companies. Named with their consent.
Confidentiality
What we may show — and what we may not
A test bench reveals what is being tested. And what is being tested is usually the next thing a competitor would like to know about.
Geometry, characteristic values, test specification and measured data belong to the client, not to us. That is why this page carries no project report, no photograph from someone else’s test field and no measurement series. Where customer names appear, written consent is on file — and where there is none, no name appears either, however well the project might tell.
We regard that as an advantage, not a restriction: whoever places an order with us can assume that their plant will likewise not appear on our website.
What we can supply: a reference extract for your specific task — anonymised, with the setup, operating ranges, the control accuracy achieved, project duration and a contact for a telephone call, where the customer agrees to it. On request and, where necessary, under a non-disclosure agreement. Tell us what you want to test — then we will pick out what fits.
Industries
Where our plants stand
Instead of individual projects, the fields we have worked in.
-
01
Automotive and supplier industry
Cooling circuits, thermal management, component and end-of-line testing in series production.
-
02
Motorsport up to Formula 1
Short development cycles, tight tolerances, test benches that are ready in time for the racing calendar.
-
03
Heat pumps and refrigeration
Performance maps over source and sink, defrost cycles, climatic chambers, series testing.
-
04
Machinery and plant engineering
Conditioning circuits and functional test benches for components of every size.
-
05
Hydraulics and drive technology
Pressure, flow rate and temperature as boundary conditions — up into the high-pressure range.
-
06
Test and measurement technology
Test benches for manufacturers of measuring instruments. We build the plant, they supply the measuring principle.
-
07
Fibre and process engineering
Media circuits for processes in which temperature and flow determine the product.
-
08
Data centre and power electronics
Liquid cooling from cold plate to CDU, thermal resistance on power modules.
The order says nothing about scope or share. Not every industry is represented with every size of plant.
Project types
What we build
Six kinds of plant, ordered by task — not by customer.
02
Development test benches
Mechanics, fluids and electronics in one plant — from the measuring task to the complex test sequence. Control via PLC and LabVIEW.
03
End-of-line test benches
Quality testing in production: short cycle times, high availability, documentation and traceability.
04
Conditioning systems of every kind
Water, glycol, oil and fuel — thermally, pressure and flow controlled. Designed to CE and ATEX requirements.
05
Integrated end-of-line lines
From feeding through test and assembly processes to evaluation and documentation — all trades interlocked.
06
Laboratory automation
Automated calibration and test lines for the laboratory, integrated into existing environments.
Tools
What we work with
Engineering design, electrical planning and test software are produced in house — with the tools that are customary in the industry.
| Tool | For what |
|---|---|
| SolidWorks | Engineering design of frames, sheet metal work and assemblies, pipework routing, manufacturing drawings and parts lists. |
| LabVIEWLabVIEW Alliance Partner | Measurement and test software, test sequences, data acquisition and test record. As an Alliance Partner we work with the same tool chain as the measurement technology companies we build for. |
| EPLAN | Circuit diagram, terminal and cable schedules, control cabinet layout and the documentation that belongs in the CE file. |
| PLC and visualisation | Plant control, closed-loop control, safety functions and operator interface — programmed by us throughout. |
| PCB design | Adapter and interface boards where there is no standard solution for the measuring task. |
The brands named are the property of the respective manufacturers.
Ask for what fits.
Tell us the test item, the medium and the ranges for pressure, flow rate and temperature — then we will tell you whether we have already built something of the kind, and send the reference extract with it.
